特点:
1.借鉴国外先进技术,加以吸收、改进、创新研制而成;
2.全变频控制,运行稳定、高高效、能耗低;
3.制品采用一次成型工艺;
4.特殊边料往返收取机构。
Feature:
1. It profits advanced technology from aboard and manufacture by absorption, improvement, innovation.
2. It is entire frequency conversion control, movement stable, highly effective and the low energy consumption.
3. The product adopts the craft of one time forming.
4. It can produce two-side sticks for stretching film.
主要技术参数(Main Technical Parameter)
型 号 | MODEL | SLW-1000 | ||
适用原料 | SUITABLE RAW MATORIAL | HDPE LDPE LLDPE | ||
模头宽度 | DIE WIDTH | 1250mm | ||
薄膜宽度 | FILM WIDTH | 1000mm/500mmX2 | ||
薄膜厚度 | FILM THICKNESS | 0.01-0.05mm | ||
收卷直径 | ROLLOUT DIAMETER | 300mm | ||
加热功率 | HEATING POWER | 70kw | ||
占地尺寸 | COVER DIMENSION(M) | 6.0*2.6*2.6 | ||
整机重量 | TOTAL WEIGHT | 6000kg | ||
产量 | OUTPUT | 缠绕膜最大挤出量(max):40-150Kg/h.
| ||
挤出机EXTRUDER | ||||
螺杆直径 | SCREW DIAMETER(mm) | Φ55/80/55 | ||
螺杆长径比 | SCREW L/D | 34:1 | ||
螺杆材料 | SCREW MATERIAL | SACM-75/38CRMOLA | ||
料筒材料 | CYLINDER MATERIAL | SACM-55/38CRMOLA | ||
主机功率 | DRIVING MOTOR(KW) | 15kw/22kw/15kw | ||
卷取装置WINDING UNIT | ||||
收卷方式 | TYPE | 表面摩擦式/中心收卷SURFACE FRICTION/CENTER REWINDER | ||
卷取功率 | WINDING MOTOR(KW) | 2.2 | ||
卷取速度 | WINDING SPEED(M/min) | 10-80 |
变频控制器 自动上料
Electric Controller Box Auto Feeding
全自动收卷
automatic rewinder
