东莞鼎顺机械制造有限公司

Mixer Total Power:

搅拌头总功率:

15KW

Mixing Speed:

搅拌速度:

0r～3000r/min

0转～3000转/分钟

Save Formular Q.T.Y.:

可储存配方数量:

20 Groups.

20组

Control System:

控制系统:

PLC Touch Screen Control System

PLC触摸屏控制系统

PPG Tank:

PPG罐:

2Ton*1Set.

2吨*1套

TDI Tank:

TDI罐:

1Ton*1Set.

1吨*1套

MC Tank:

MC罐:

0.5Ton*1Set.

0.5吨*1套

Auto Loading Pumps For PPG,POP,TDI,MC:

大料自动上料泵:

3Sets(“Line”Brand Made In China)

3套( 国产莱恩品牌)

Transducers:

减速机:

3Sets

3套

Chiller(Both Cooling & Heating System):

冷热水一体机:

1Set*7.5KW

1台*7.5KW

Oil Hydraulic System:

油压系统:

1Set

1套

Air Compressor:

空气压缩机:

1Set*2.2KW

1套*2.2KW

Water Tower:

水塔:

1Set

1套

Water Pump:

水泵:

1Set.

1套

Foaming Density Range:

发泡密度范围:

8～50kg/Cubicmeter.

8～50kg/立方.

Outputs:

产量:

48 Blocks/per day/8hrs

可生产泡绵48个/天/8小时

Match Mould（2sets Squre or 1set Cylinder Mould as requirement）:

配模具（方模2套或圆模1套根据需求）:

L2100mm*W2100mm*H1220mm

Dia1800mm*H2200mm

(To Be Requested)

Total Motor Power:

机器总功率:

Approx 35KW.

约35KW.

Machine N.W.:

机器总重量:

Approx 6Ton

约6吨

Floor Space Required:

占地尺寸:

L10m*W10m*H6m.
