| 颜色 | 本色 |
|---|---|
| 邵氏硬度 | 65D |
| 产品名称 | PA12 |
| 名称 | PA12 |
| 牌号 | L25W20X |
| 销售方式 | 自产自销 |
| 用途级别 | 板材级,电线电缆级,管材级,汽车部件,型材 |
| 厂家(产地) | 瑞士EMS |
| 加工级别 | 挤出级 |
| 特性级别 | 耐低温 |
PA12 瑞士EMS L25W20X，添加增塑剂，
特点：经增塑，抗撞击性高，抗紫外线性好，良好的柔韧性，耐热性中等，粘度高。
用途:电气电子应用，电线电缆应用，气动应用，液压应用，管道。
加工成型：挤出成型。
物性：收缩率0，8-1，2%，吸水率0，7-1，5%，支持硬度65D，热变形温度45-95**使用温度：长时间80-110℃，短时间150℃，熔融温度174℃，表面电阻率1，0E+12ohm，体积电阻率1，0E+13ohm。
The family of Grilamid PA12 FWA products offers plenty of new possibilities in the areas of food or potable water contact components.
Grilamid PA12 products have remarkable properties such as:
Very low water absorption, high dimensional stability Excellent chemical and UV resistance Strong hydrolysis resistance High impact strength and high elongation when compared to other polymers with an identical stiffness Very favorable molding conditions thanks to low tooling and material temperatures compared to most other engineering plasticsGrilamid FWA products are available in two distinct series, specific to maximum applicable temperatures in contact with potable water.
| In water up to 60 °C | In water up to 85 °C |
| Grilamid LV-30H FWA | Grilamid LBV-30H FWA |
| Grilamid LV-50H FWA | Grilamid LBV-50H FWA |
| Grilamid LV-65H FWA | Grilamid LBV-65H FWA |
Beside the above standard Grilamid FWA grades in natural and black, specific custom colors are possible, even for small delivery sizes.
Grilamid FWA products are compliant or homologated with regard to the most important standards and regulations in Europe and North America, such as WRAS, ACS, KTW, NSF and FDA. Detailed data on compliance and homologations is available on each specific datasheet, which can be downloaded from this site.
EMS Material Database
For further details such as long term behavior in water according to ISO 9080 please contact your nearest EMS-GRIVORY sales office or representative.
Grilamid FWA products have been especially developed for the replacement of more costly metal and high performance polymers. Their favorable molding conditions make them particularly suitable for large and thick-walled as well as thin components difficult or impossible to mold with other polymers.
Grilamid FWA products nicely complement the Grivory GV...FWA and Grivory HT…FWA product lines, also available from EMS-GRIVORY for potable water and food contact components.
