产品名称 | PPA原料 |
---|---|
牌号 | HTNFR52G30BL |
用途级别 | 注塑 |
产地/厂家 | 美国杜邦 |
蓝臣公司主要销售杜邦公司的Zytel HTN PPA原料:
Zytel HTNFR52G30BL NC010| PPA-GF30 FR
Zytel HTNFR52G30BL BK337| PPA-GF30 FR
高性能聚酰胺树脂PPA原料
材料特点:
地区供应:北美,欧洲,亚太,南美和中美洲,中东/非洲,全球
处 理:注塑
供货形式:颗粒
添 加 剂:润滑剂,脱模剂
产品说明:
的Zytel?HTN高性能聚酰胺树脂配在暴露于升高的温度高保持特性,对高水分,以及苛刻的化学环境。聚合物家庭和HTN的Zytel?档次都量身定制,以优化性能和加工性能。
PPA原料的应用:
Zytel?的 HTN PPA 典型应用包括苛刻的应用在汽车,电子电气,家用电器,建筑等行业。..
美国杜邦PPA Zytel HTNFR52G30BL NC010是30%玻璃纤维增强,阻燃,已开发连接器应用润滑高性能聚酰胺树脂。
注塑
预处理
干燥推荐=是,如果树脂的水分含量超过建议的水平
干燥温度为100℃,
干燥时间,除湿机=6-8?
处理含水量=<0.1%
处理
熔体温度**适=325℃
熔体温度范围=320-330℃,
模具温度范围=85-105℃,
在成型,使用适当的防护设备和足够的通风。避免接触烟雾,并限制在机树脂的保持时间和温度。仔细清除降解树脂与HDPE。
Dupont Zytel HTN PA:
Zytel? HTNFR52G30BL NC010 | PA6T/66-GF30 FR
Zytel? HTNFR52G30BL BK337 | PA6T/66-GF30 FR
HIGH PERFORMANCE POLYAMIDE RESIN
Characteristics
Regional Availability : North America, Europe, Asia Pacific, South and Central America, Near East/Africa, Global
Processing : Injection Moulding
Delivery form : Pellets
Additives : Lubricants, Release agent
Product Text
Zytel? HTN high performance polyamide resins feature high retention of properties upon exposure to elevated temperature, to high moisture, and to harsh chemical environments. Polymer families and grades of Zytel? HTN are tailored to optimize performance as well as processability.
Typical applications with Zytel? HTN include demanding applications in the automotive, electrical and electronics, domestic appliances, and construction industries.
Zytel? HTNFR52G30BL NC010 is a 30% glass reinforced, flame retardant, lubricated high performance polyamide resin that has been developed for connector applications.
Injection molding
PREPROCESSING
Drying recommended = Yes, if moisture content of resin exceeds recommended level
Drying temperature = 100°C
Drying time, dehumidified dryer = 6-8 h
Processing moisture content = <0.1 %
PROCESSING
Melt temperature optimum = 325°C
Melt temperature range = 320-330°C
Mold temperature range = 85-105°C
During molding, use proper protective equipment and adequate ventilation. Avoid exposure to fumes and limit the hold up time and temperature of the resin in the machine. Purge degraded resin carefully with HDPE.
