| 计量单位 | 吨 |
|---|---|
| 类型 | 标准料 |
| 牌号 | EVA/美国杜邦/40L-03/耐高温/高粘度 |
| 销售方式 | 品牌经销 |
| 厂家(产地) | 美国杜邦 |
产品参数
| 性能项目 | 试验条件[状态] | 测试方法 | 测试数据 | 数据单位 | |
| 物理性能 | 密度 | ASTM D-792/ISO 1183 | 0.967 | g/cm3 | |
| 熔体流动速率 | 190/2.16kg | ASTM D-1238/ISO 1133 | 3 | g/10min | |
| VA含量 | 40 | % | |||
| 热性能 | 熔点(DSC) | ASTM D-3418/ISO 3146 | 58(136) | ℃(°F) | |
| 冰点(DSC) | ASTM D-3418/ISO 3146 | 26(79) | ℃(°F) | ||
The melt index is consistent because resin molecular weight distribution is controlled to within a relatively narrow range. The molecular weight is high for this family of copolymers, so finished products will be relatively resistant to mechanical damage and elevated temperatures.
Compared with other ethylene/vinyl acetate copolymers, Elvax? 40L-03 contains extremely low amounts of gel, or high-molecular-weight polymer, that can cause undesirable characteristics in finished products.
Because Elvax? 40L-03 is somewhat crystalline, it is free flowing and does not mass during handling.
Uses
Industrial Applications zWire & Cable ApplicationsWire Jacketing
Composition
40 % By Weight Vinyl Acetate comonomer contentThermal Stabilizer: BHT antioxidant
Features
High Molecular Weight, High Viscosity
Applications
Elvax? resins can be used in a variety of applications involving molding, compounding, extrusion, adhesives, sealants, and wax blends. For additional information and properties associated with specific applications, please refer to the Grade Selector Guides found on the Elvax? website for industrial applications: //www2.dupont.com/Elvax/en_US/tech_info/index.html
Elvax?40L-03 is especially well suited for use in jacketing compounds for automotive ignition and low-smoke cables, and as strippable semiconductive shields for power cables.
In these applications, the relatively narrow molecular weight distribution and the low gel properties help ensure that compounds will be consistent and finished products will be smooth-surfaced. Smooth, glossy surfaces are desirable because they can imply quality, while uniformity can enhance long-term performance.
Power cable semiconductive shields made with Elvax?40L-03 also benefit from the consistency of their compounds and low gel content. Any inconsistency in shields can lead to cable failure.单位: 公制 | 英制Properties 处理 资料 视觉搜索 曲线数据 购买地点
| 总体 | ||||
| 材料状态 | 已商用：当前有效 | |||
| 资料 1 |
| |||
| 搜索 UL 黄卡 | DuPont Packaging & Industrial Polymers | |||
| 供货地区 |
| |||
| 添加剂 |
| |||
| 特性 |
| |||
| 用途 |
| |||
| 机构评级 | FDA 21 CFR 177.1350 (d) | |||
| 形式 | 粒子 | |||
| 加工方法 |
|
| 物理性能 | 额定值 | 单位制 | 测试方法 |
| 比重 | |||
| -- | 0.969 | ASTM D792 | |
| -- | 0.967 | g/cm3 | ISO 1183 |
| 熔流率（熔体流动速率） (190°C/2.16 kg) | 3.0 | g/10 min | ASTM D1238, ISO 1133 |
| 醋酸乙烯含量 | 40.0 | wt% |
| 热性能 | 额定值 | 单位制 | 测试方法 |
| 熔融峰值温度 | 136 | °F | ASTM D3418, ISO 3146 |
| Freezing Point 2 | |||
| -- | 79 | °F | ISO 3146 |
| -- | 79 | °F | ASTM D3418 |
| 注射 | 额定值 | 单位制 | |
| 加工（熔体）温度 | < 446 | °F | |
| 挤出 | 额定值 | 单位制 | |
| 熔体温度 | < 446 | °F |
| 备注 |
| 1通过这些链接您能够访问供应商资料。我们尽量保证及时更新资料；不过您可以从供应商处了解最新资料。 |
| 2DSC |
添加到 Prospector： 2000年11月
上次更新： 2014/11/24 UL 和 UL 徽标为 UL LLC ? 的商标 2015。保留所有权利。 UL Prospector
此数据表中的信息由 UL Prospector 从该材料的生产商处获得。UL Prospector 尽最大努力确保此数据的准确性。 但是 UL Prospector 对这些数据值不承担任何责任，并强烈建议在最终选择材料前，就数据值与材料供应商进行验证。
