| 牌号 | A150 |
|---|---|
| 销售方式 | 品牌经销 |
| 用途级别 | 瓶盖专用料 |
| 厂家(产地) | 伊士曼化学 |
| 加工级别 | 注塑级 |
| 特性级别 | 抗化学性,耐高温 |
应用/用途
吸塑包装
食品包装
食品接触应用
肉品包装
家禽包装
| Product Data Sheet Eastar™ Copolyester A150 | ||||||
| ||||||
| ||||||
| Typical Properties | ||||||
| Propertya | Testb Method | Typical Value, Unitsc | ||||
| Pellet Properties | ||||||
| Inherent Viscosity | EMN-A-AC-G-V-1 | 0.77 | ||||
| Density | D 1505 | 1.2 g/cm3 | ||||
| Bulk Density | ||||||
| D 1895 | 670 kg/m3(42 lb/ft3) | ||||
| D 1895 | 730 kg/m3(46 lb/ft3) | ||||
| Crystalline Peak Melting Point (Tm) d | D 3418 | 261°C (502°F) | ||||
| Glass Transition Temperature (Tg) d | D 3418 | 91°C (196°F) | ||||
| Heat of Fusion e | E 793 | 32 kJ/kg (7.6 cal/g) | ||||
| Specific Heat e | ||||||
| DSC | 1.2 kJ/kg·K (0.29 Btu/lb·°F) | ||||
| DSC | 1.4 kJ/kg·K (0.33 Btu/lb·°F) | ||||
| DSC | 1.7 kJ/kg·K (0.41 Btu/lb·°F) | ||||
| DSC | 1.9 kJ/kg·K (0.45 Btu/lb·°F) | ||||
| DSC | 2.2 kJ/kg·K (0.53 Btu/lb·°F) | ||||
| Film Properties | ||||||
| Inherent Viscosity (film) | EMN-A-AC-G-V-1 | 0.73 | ||||
| Thickness of Film Tested | D 374 | 280 microns (11 mils) | ||||
| Density (film) | D 1505 | 1.2 g/cm3 | ||||
| Haze | D 1003 | 0.5% | ||||
| Gloss @ 45° | D 2457 | 108 | ||||
| Transparency | D 1746 | 85% | ||||
| Regular Transmittance | D 1003 Modified | 90% | ||||
| Total Transmittance | D 1003 Modified | 93% | ||||
| Water Vapor Transmission Rate f | F 372 | 5 g/m2·24h (0.3 g/100in.2·24h ) | ||||
| Gas Permeability, CO2 | D 1434 | 59 cm3·mm/m2·24h·atm (150 cm3·mil/100in.2·24h·atm ) | ||||
| Gas Permeability, O2 | D 3985 | 13 cm3·mm/m2·24h·atm (33 cm3·mil/100in.2·24h·atm ) | ||||
| Elmendorf Tear Resistance | ||||||
| D 1922 | 16 N (1600 gf) | ||||
| D 1922 | 17 N (1700 gf) | ||||
| Tear Propagation Resistance, Split Tear Method | ||||||
| D 1938 | 19 N/mm (108 lbf/in.) | ||||
| D 1938 | 18 N/mm (103 lbf/in.) | ||||
| Tensile Strength @ Yield | ||||||
| D 882 | 43 MPa (6200 psi) | ||||
| D 882 | 43 MPa (6200 psi) | ||||
| Tensile Strength @ Break | ||||||
| D 882 | 56 MPa (8100 psi) | ||||
| D 882 | 56 MPa (8100 psi) | ||||
| Elongation @ Yield | ||||||
| D 882 | 5% | ||||
| D 882 | 5% | ||||
| Elongation @ Break | ||||||
| D 882 | 250% | ||||
| D 882 | 250% | ||||
| Tensile Modulus | ||||||
| D 882 | 1600 MPa (2.32 x 105psi ) | ||||
| D 882 | 1600 MPa (2.32 x 105psi ) | ||||
| Dart Impact g | ||||||
| D 1709A Modified | 680 g | ||||
| D 1709A Modified | 750 g | ||||
| D 1709A Modified | 710 g | ||||
| Coefficient of Friction | D 1894 | 0.6 | ||||
我司长期供应：
PCTG/伊斯曼化学/TX1001 透明级、耐高温；注塑级；食品级
PCTG/伊斯曼化学/TX2001 透明级、耐高温；食品级
PCTG/伊斯曼化学/GN071 透明级；食品级
PCTG/伊斯曼化学/DN011 透明级、高抗冲；注塑级；食品级
PCTG/伊斯曼化学/Z6008 透明级；食品级
PCTG/伊斯曼化学/EX401 透明级、耐高温；吹塑级；食品级
PCTG/伊斯曼化学/6018 透明级；注塑级
PCTG/伊斯曼化学/6002 透明级
PCTG/伊斯曼化学/DN001
PCTG/伊斯曼化学/Z6013 透明级；挤出级；食品级
PCTG/伊斯曼化学/EX301 透明级
PCTG/伊斯曼化学/Z6015 透明级；食品级
PCTG/伊斯曼化学/TX1501HF 注塑级、；食品级、医用级
PCTG/伊斯曼化学/EB062 透明级
PCTG/伊斯曼化学/Z6020 透明级
PCTG/伊斯曼化学/WX510 透明级
PCTG/伊斯曼化学/DN003
PCTG/伊斯曼化学/Z6018-BL
PCTG/韩国SK/JN-200 食品级
PCTG/韩国SK/J2003
