首页 > 供应产品 > 特价原装汉高乐泰365厌氧胶 紫外线密封剂
特价原装汉高乐泰365厌氧胶 紫外线密封剂
产品: 浏览次数:685特价原装汉高乐泰365厌氧胶 紫外线密封剂
厂家: -
牌号: -
单价: 50.00元/瓶
最小起订量:
供货总量:
发货期限: 自买家付款之日起 天内发货
有效期至: 长期有效
最后更新: 2021-09-16 12:31

详细信息
厂家 -
牌号 -
用途级别 -
品牌 乐泰
型号 365

粘合材料类型:玻璃,电子元件,金属类,其他树脂胶的分类:丙烯酸酯胶
热熔胶类型:其他热熔胶剪切强度:25200(MPa)
有效物质≥:90(%)活性使用期:2(min)
工作温度:85(℃)保质期:24(个月)
执行标准:COCCAS:SGS
应用领域:电子,工业等

价格50元代表面议

产品简介
乐泰®产品365 是一种单组分,中等粘度的厌氧型
紫外线固化胶粘剂/密封剂。厌氧固化时需使用活
化剂707 或加热。
典型用途
本产品用于电路接头的密或封装以提高其耐候
性。由于本产品综合了紫外线固化和厌氧固化两
者的优点,因此比产品363 具有更深的封装性
能,建议用于消除应变和防干扰的场合。

PRODUCT DEscriptION
LOCTITE® Product 365 is a single component, medium
viscosity adhesive/sealant with anaerobic and ultra violet
radiation cure systems.
TYPICAL APPLICATIONS
This product is used to seal or encapsulate electrical terminals
against atmospheric conditions. The combination ultra violet
and anaerobic cure system permits deeper potting than
Product 363 and is also recommended for strain relief and
tamperproofing.
PROPERTIES OF UNCURED MATERIAL
Typical
Value Range
Chemical Type Urethane methacrylate
Appearance Clear, amber
Specific Gravity @ 25°C 1.1
Viscosity @ 25°C, mPa.s (cP)
Brookfield RVT
Spindle #3 @ 20 rpm 2,100 1,200 to 3,000
Flash Point (TCC), °C >93
TYPICAL CURING PERFORMANCE
This product is cured when exposed to UV radiation of 365nm.
To obtain a full cure on surfaces exposed to air, radiation at
250nm is also required. The speed of cure will depend on the
UV intensity as measured at the product surface. Typical cure
condition is 20 - 30 seconds at 100mW/cm² using a medium
pressure, quartz envelope, mercury vapor UV lamp.
NOTE: UV intensities where quoted are measured at
365nm using an OAI 206 UV meter.

TYPICAL PROPERTIES OF CURED MATERIAL
Physical Properties
Coefficient of thermal expansion mm/(m.K) 0.1
Coefficient of thermal conductivity, , W/(m.k) 0.1
Hardness (Shore D), ASTM-D2240 60
Electrical Properties Constant Loss
Dielectric constant & loss, ASTM D150 @ 1 kHz 4.2 0.04
Volume resistivity, ASTM D257, W - cm 2x1014
Dielectric strength, ASTM D149, kV/mm 32
PERFORMANCE OF CURED MATERIAL
(Cured 20 secs @ 100mW/cm², 365nm UV)
Typical
Value Range
Tensile strength, steel to glass, N/mm2
(modified ASTM D2095/modified DIN 53288)
8 3 to 12
Secondary Cure
Tensile strength, grit blasted mild steel 22°C with
Heat (without UV), 24 hr. ASTM D1002, N/mm2
20 15 to 25
Tensile strength is measured using a test method based on
ASTM D2095. A metal pin (Ø12.7mm x 38mm) is bonded at
one end to 6mm thick Pilkington float glass (50mm x 50mm).
The pin is then pulled axially from the glass.

GENERAL INFORMATION
This product is not recommended for use in pure oxygen
and/or oxygen rich systems and should not be selected as
a sealant for chlorine or other strong oxidising materials.

This product is UV sensitive. Exposure to daylight, UV light
and artificial lighting should be kept to a minimum during
storage and handling. Product should be dispensed from
applicators with black feed lines. For best performance bond
surfaces should be clean and free from grease.
UV light cure rate is dependent on lamp intensity, distance
from light source, depth of cure needed or bondline gap and
light transmittance of the substrate through which the radiation
must pass.
Recommended intensity for cure in bondline situation is
5mW/cm2 minimum (measured at the bondline) with an
exposure time of 4-5 times the fixture time at this same
intensity. For dry curing of exposed surfaces higher intensity
UV is required (100W/cm2 minimum).
Cooling should be provided for temperature sensitive substrate
such as thermoplastics. Plastic grades should be checked for
risk of stress cracking when exposed to liquid adhesive.
Excess adhesive can be wiped away with organic solvent.
Bonds should be allowed to cool before subjecting to any
service loads.

Storage
Products shall be ideally stored in a cool, dry location in
unopened containers at a temperature between 8°-21°C (46°-
70°F) unless otherwise labelled. The shelf-life period for a
250ml container is 12 months based upon date of
manufacture. To prevent contamination of unused product,
do not return any material to its original container.
