| 牌号 : | 101L NC010 | 加工级别 : | 注塑级 |
| 特性级别 : | 增强级 | 用途级别 : | 通用级 |
| 品牌 : | 美国杜邦 |
DuPont Performance Polymers Zytel® 101L NC010 Nylon 66 (Unverified Data**)
Polymer,Thermoplastic,Nylon,Nylon 66
DuPont Performance Polymers
产品说明:
Unreinforced Polyamide 66
Zytel 101L NC010 is a lubricated polyamide 66 resin for injection molding.
Information provided by DuPont Performance Polymers
] |
DuPont Performance Polymers Zytel® 101L NC010 Nylon 66 (Unverified Data**) 物性表
| 物理性能 | 额定值 (公制) | 额定值 (英制) | 测试方法 |
|---|---|---|---|
| 密度 | 0.970 g/cc | 0.0350 lb/in³ | |
| 1.14 g/cc | 0.0412 lb/in³ | DAM; ISO 1183 | |
| 吸水率 | 8.5 % @Thickness 2.00 mm | 8.5 % @Thickness 0.0787 in | DAM; Sim. to ISO 62 |
| 水分吸收 | 2.60 % @Thickness 2.00 mm | 2.60 % @Thickness 0.0787 in | DAM; Sim. to ISO 62 |
| 粘度 | 42820 cP @Shear Rate 5000 1/s, Temperature 300 °C | 42820 cP @Shear Rate 5000 1/s, Temperature 572 °F | ISO 11403-1 -2 |
| 51190 cP @Shear Rate 5000 1/s, Temperature 290 °C | 51190 cP @Shear Rate 5000 1/s, Temperature 554 °F | ISO 11403-1 -2 | |
| 61310 cP @Shear Rate 5000 1/s, Temperature 280 °C | 61310 cP @Shear Rate 5000 1/s, Temperature 536 °F | ISO 11403-1 -2 | |
| 72990 cP @Shear Rate 500 1/s, Temperature 300 °C | 72990 cP @Shear Rate 500 1/s, Temperature 572 °F | ISO 11403-1 -2 | |
| 95840 cP @Shear Rate 500 1/s, Temperature 290 °C | 95840 cP @Shear Rate 500 1/s, Temperature 554 °F | ISO 11403-1 -2 | |
| 127400 cP @Shear Rate 500 1/s, Temperature 280 °C | 127400 cP @Shear Rate 500 1/s, Temperature 536 °F | ISO 11403-1 -2 | |
| 粘度测试 | 150 cm³/g | 150 cm³/g | DAM; ISO 307 1157 1628 |
| 线性成型收缩率,Flow | 0.014 cm/cm | 0.014 in/in | DAM; ISO 294-4 2577 |
| 线性成型收缩率，横向 | 0.014 cm/cm | 0.014 in/in | DAM; ISO 294-4 2577 |
| 机械性能 | 额定值 (公制) | 额定值 (英制) | 测试方法 |
|---|---|---|---|
| 洛氏硬度（M 级） | 59 | 59 | 50%RH; ISO 2039-2 |
| 79 | 79 | DAM; ISO 2039-2 | |
| 洛氏硬度（R 级） | 108 | 108 | 50%RH; ISO 2039-2 |
| 121 | 121 | DAM; ISO 2039-2 | |
| 硬度，H358/30 | 85.0 MPa | 12300 psi | 50%RH; ISO 2039-1 |
| 180 MPa | 26100 psi | DAM; ISO 2039-1 | |
| 抗张强度 | 2.00 MPa @Strain 0.135 %, Time 3600 sec | 290 psi @Strain 0.135 %, Time 1.00 hour | 50%RH; isochronous; ISO 11403-1 -2 |
| 2.00 MPa @Strain 0.157 %, Time 36000 sec | 290 psi @Strain 0.157 %, Time 10.0 hour | 50%RH; isochronous; ISO 11403-1 -2 | |
| 2.00 MPa @Strain 0.192 %, Time 360000 sec | 290 psi @Strain 0.192 %, Time 100 hour | 50%RH; isochronous; ISO 11403-1 -2 | |
| 2.00 MPa @Strain 0.305 %, Time 3.60e+7 sec | 290 psi @Strain 0.305 %, Time 10000 hour | 50%RH; isochronous; ISO 11403-1 -2 | |
| 2.00 MPa @Strain 0.239 %, Time 3.60e+6 sec | 290 psi @Strain 0.239 %, Time 1000 hour | 50%RH; isochronous; ISO 11403-1 -2 | |
| 12.0 MPa @Strain 1.95 %, Time 3.60e+6 sec | 1740 psi @Strain 1.95 %, Time 1000 hour | 50%RH; isochronous; ISO 11403-1 -2 | |
| 12.0 MPa @Strain 2.50 %, Time 3.60e+7 sec | 1740 psi @Strain 2.50 %, Time 10000 hour | 50%RH; isochronous; ISO 11403-1 -2 | |
| 12.0 MPa @Strain 1.52 %, Time 360000 sec | 1740 psi @Strain 1.52 %, Time 100 hour | 50%RH; isochronous; ISO 11403-1 -2 | |
| 12.0 MPa @Strain 1.25 %, Time 36000 sec | 1740 psi @Strain 1.25 %, Time 10.0 hour | 50%RH; isochronous; ISO 11403-1 -2 | |
| 12.0 MPa @Time 3600 sec, Strain 1.02 % | 1740 psi @Time 1.00 hour, Strain 1.02 % | 50%RH; isochronous; ISO 11403-1 -2 | |
| 24.0 MPa @Time 3600 sec, Strain 3.29603 % | 3480 psi @Time 1.00 hour, Strain 3.29603 % | 50%RH; isochronous; ISO 11403-1 -2 | |
| 24.0 MPa @Strain 3.91667 %, Time 36000 sec | 3480 psi @Strain 3.91667 %, Time 10.0 hour | 50%RH; isochronous; ISO 11403-1 -2 | |
| 抗张强度(屈服) | 55.0 MPa | 7980 psi | 50%RH; ISO 527-1/-2 |
| 82.0 MPa | 11900 psi | DAM; ISO 527-1/-2 | |
| 伸长率 (断裂) | 25 % | 25 % | DAM; Nominal; ISO 527-1/-2 |
| >= 50 % | >= 50 % | 50%RH; Nominal; ISO 527-1/-2 | |
| 屈服伸长率 | 4.5 % | 4.5 % | DAM; ISO 527-1/-2 |
| 4.5 % | 4.5 % | DAM; ISO 527-3 | |
| 25 % | 25 % | 50%RH; ISO 527-1/-2 | |
| 拉伸模量 | 1.40 GPa | 203 ksi | 50%RH; ISO 527-1/-2 |
| 3.10 GPa | 450 ksi | DAM; ISO 527-1/-2 | |
| 0.373 GPa @Temperature 120 °C | 54.1 ksi @Temperature 248 °F | 50%RH; ISO 11403-1 -2 | |
| 0.460 GPa @Temperature 120 °C | 66.7 ksi @Temperature 248 °F | DAM; ISO 11403-1 -2 | |
| 0.945 GPa @Temperature 40.0 °C | 137 ksi @Temperature 104 °F | 50%RH; ISO 11403-1 -2 | |
| 2.769 GPa @Temperature 40.0 °C | 401.6 ksi @Temperature 104 °F | DAM; ISO 11403-1 -2 | |
| 3.555 GPa @Temperature -40.0 °C | 515.6 ksi @Temperature -40.0 °F | DAM; ISO 11403-1 -2 | |
| 4.493 GPa @Temperature -40.0 °C | 651.7 ksi @Temperature -40.0 °F | 50%RH; ISO 11403-1 -2 | |
| 弯曲模量 | 1.20 GPa | 174 ksi | 50%RH; ISO 178 |
| 2.80 GPa | 406 ksi | DAM; ISO 178 | |
| 剪切模量 | 0.154 GPa @Temperature 160 °C | 22.3 ksi @Temperature 320 °F | 50%RH; Dynamic; ISO 11403-1 -2 |
| 0.160 GPa @Temperature 160 °C | 23.2 ksi @Temperature 320 °F | DAM; Dynamic; ISO 11403-1 -2 | |
| 0.180 GPa @Temperature 120 °C | 26.1 ksi @Temperature 248 °F | DAM; Dynamic; ISO 11403-1 -2 | |
| 0.180 GPa @Temperature 120 °C | 26.1 ksi @Temperature 248 °F | 50%RH; Dynamic; ISO 11403-1 -2 | |
| 0.240 GPa @Temperature 70.0 °C | 34.8 ksi @Temperature 158 °F | 50%RH; Dynamic; ISO 11403-1 -2 | |
| 0.335 GPa @Temperature 70.0 °C | 48.6 ksi @Temperature 158 °F | DAM; Dynamic; ISO 11403-1 -2 | |
| 0.880 GPa @Temperature 20.0 °C | 128 ksi @Temperature 68.0 °F | 50%RH; Dynamic; ISO 11403-1 -2 | |
| 0.919 GPa @Temperature 20.0 °C | 133 ksi @Temperature 68.0 °F | DAM; Dynamic; ISO 11403-1 -2 | |
| 1.02 GPa @Temperature -20.0 °C | 148 ksi @Temperature -4.00 °F | DAM; Dynamic; ISO 11403-1 -2 | |
| 1.04 GPa @Temperature -20.0 °C | 151 ksi @Temperature -4.00 °F | 50%RH; Dynamic; ISO 11403-1 -2 | |
| 1.11 GPa @Temperature -50.0 °C | 161 ksi @Temperature -58.0 °F | DAM; Dynamic; ISO 11403-1 -2 | |
| 1.15 GPa @Temperature -50.0 °C | 167 ksi @Temperature -58.0 °F | 50%RH; Dynamic; ISO 11403-1 -2 | |
| 悬壁梁缺口冲击强度 | 5.50 kJ/m² | 2.62 ft-lb/in² | DAM; ISO 180/1A |
| 12.0 kJ/m² | 5.71 ft-lb/in² | 50%RH; ISO 180/1A | |
| 3.00 kJ/m² @Temperature -30.0 °C | 1.43 ft-lb/in² @Temperature -22.0 °F | 50%RH; ISO 180/1A | |
| 5.50 kJ/m² @Temperature -40.0 °C | 2.62 ft-lb/in² @Temperature -40.0 °F | DAM; ISO 180/1A | |
| 5.50 kJ/m² @Temperature -30.0 °C | 2.62 ft-lb/in² @Temperature -22.0 °F | DAM; ISO 180/1A | |
| 悬壁梁无缺口冲击强度 | NB | NB | DAM; ISO 180/1U |
| NB | NB | 50%RH; ISO 180/1U | |
| 300 kJ/m² @Temperature -30.0 °C | 143 ft-lb/in² @Temperature -22.0 °F | DAM; ISO 180/1U | |
| 简支梁无缺口冲击强度 | NB | NB | DAM; ISO 179/1eU |
| NB | NB | 50%RH; ISO 179/1eU | |
| 40.0 J/cm² @Temperature -30.0 °C | 190 ft-lb/in² @Temperature -22.0 °F | DAM; ISO 179/1eU | |
| NB @Temperature -30.0 °C | NB @Temperature -22.0 °F |
