品牌 | HOUSEN |
---|---|
型号 | HSH |
一、主要性能和结构特点
I. Principal capability and stuctural features:
袋长无需人工设定,设备运行中自动检测,自动设定,双变频简约机械结构,易维护、磨损少,寿命长。
The bag length is free of manual seting,the equipment may automatically detect and set the length.Simplified mechanic gearing,easy to maintain,little vibration,littlewear and long life.
主控电路采用本公司研制的PLC,中英文显示,变频器控制,良好的人机界面,操作集中直观、方便。
The main control circuit takes PLC develop oped by our own company ,kigital screen display and controlled by transducer.Perfect inter face between operator and machine.integrated,direct adndconvenient operation.
包装速度和成袋长度采用双变频器控制。无级变速,调节范围宽,可以与生产线的前道工序**匹配。
The capacity and the length of bag take double frequency converter control with stepless speed shift and wide adjustment,it can match well with the former working procedure of production line.
高感光电眼自动准确跟踪。
Hight sensitive respond photoelectric device can follow automatically and accurately.
各封口温度独立控制,适合多种包装材料,封口美观牢固。
Independent temperature control for each sealer to make the beautiful and tight sealing and suitable for a wide variety of flecible packing material.
二、适用范围
适用于肉脯、饼干、面包、月饼、糖果、药品、日常用品、五金零件、纸盒或托盘等各类固态物体的包装。
II.Applications:
Applicable for packing various solid regular objects,such as bsiscuits , bread, mooncake, candy, medicine, hardware or loaded by box/tray …etc.Any kind of products and so on.
三、技术参数
III.specification:
机型Type | HSH-120 |
包装速度Packing speed | 35-235bags/min |
制袋尺寸Bag size | (L)65-160mm (W)35-100mm (H)5-35mm |
包装膜宽Film width | 90-240mm |
包装材料Packing material | OPP/CPP、PT/PE、KOP/CPP、ALU-FOIL |
外形尺寸Dimension | (L)4000*(W)920*(H)1600mm |
总功率Total power | 3.4kw(220v) |
