| 种类 | 其它 |
|---|---|
| 屏幕尺寸 | 16.4 |
| 品牌 | 深圳捷鸿超声 |
| 型号 | 定制 |
工艺流程：
入料—切液—洗剂刷洗—洗剂超声波清洗—切液—纯水刷洗—纯水超声波清洗—切液—纯水喷淋—切液—IR烘干—UV光清洗—高效风冷(除静电)—出料
Process:
Input feed - liquid drying - Lotion rolling brush washing - Lotion ultrasonic cleaning - liquid dr** rolling brush washing - DI ultrasonic cleaning - liquid dr** spray washing - liquid drying - IR drying - UV light cleaning - Cooling（Eliminating static） - Output feed
产品描述：
◆PLC程序自动控制与宽屏触摸屏人机界面。
◆整机采用PVC及不锈钢材料制作，洁净美观。
◆采用螺旋齿轮传动，主传动与输送腔室隔离。
◆喷淋、刷洗、超声交替结合，有效去除污染物，滚刷高度及转速可调。
◆配备自动加药装置，密封盖板及双水封结构，防止药气外泄。
Product description：
◆PLC program control and widescreen touch interface.
◆The machine made PVC and stainless steel, clean and good looking.
◆Using spiral gearing driving and separate the main drive and conveyor chamber.
◆Spraying, brushing and ultrasonic to effective removal of pollutants, the rolling brush height and speed adjustable
◆Equipped with automatic dosing device, sealed cover and double water seal structure to prevent drug leaking.
技术参数：（Technical parameters）
设备尺寸（Equipment dimension）:12000*2000*1800mm(L*W*H)
基板尺寸（Glass dimension）:14"x16"
玻璃厚度（Glass thickness）:0.4-1.1mm
传送速度（Conveying speed）:0.4-4m/min
建议生产速度（Suggest conveying speed）:2-2.5 m/min
输送面高度（Conveying height）:950mm
