用途:材料
类型:标准料
起订:1千克
供应:9999千克
| 用途 | 材料 |
|---|---|
| 类型 | 标准料 |
| 牌号 | OLLOY 欧龙优 |
| 用途级别 | 电动工具配件,电线电缆级,电子电器部件,管材级,家电部件,汽车部件,通用级 |
| 厂家(产地) | 自产 |
| 加工级别 | 注塑级,挤出级 |
| 特性级别 | 高光泽,高滑动,高抗冲,高流动,热稳定性,标准级,高刚性,耐磨,耐高温,耐低温,高强度,增强级,阻燃级,增韧级,抗静电,耐老化 |
无卤阻燃MPPO(MPPE)电缆外被料
OLLOY KMDE为电线电缆挤出系列产品原料，具有优异的柔韧性、阻燃性能和表面光洁度，被广泛地应用于直流电电线，电气产品电线，电子线，信号线，以及电信设施电线，汽车配线等等。目前本公司的该系列产品已经成为国内外知名电子和通讯设备品牌重点使用的无卤线材原材料。
OLLOY KMDE series of products have excellent flexibility, flame resistance and surface finish. These materials are widely used for various of DC cables,electrical product wires , earphone cables, USB cables, computer peripheral cables, electronic wires, signal lines, telecommunication facilities cables and Various automotive wires,etc. At present, our company’s products have become key non-halogen wire materials of well-known brands of electronic and communications equipment.
1、OLLOY KMDE系列产品性能（The physical date）
Unit | Standard | KMDE95L KMDE90L KMDE85L KMDE80L KMDE75L KMDE65L | |
Hardness, Shore A |
| ASTM ISO868 | 95 90 85 80 75 65 |
Specific Gravity |
| D790 | 1.05 1.04 1.06 1.08 1.08 1.08 |
Tensile Stress, brk | MPa | D638 | 23.3 19.5 16.6 15.5 13.0 10.2 |
Tensile Elongation, brk | % | D638 | 260 230 232 215 205 192 |
Tensile Stress retention rate, brk after 7days @113°C | MPa | UL1581 | 106 105 108 103 108 91 |
Tensile Elongation Retention Rate,brk after 7days @113°C | % | UL1581 | 94 95 88 89 83 81 |
Thermal Shocks(1hr@121°C) |
| UL1581 | No cracks No cracks No cracks No cracks No cracks No cracks |
Brittleness Temperature | ℃ | D746 | <-40 <-40 <-40 <-40 <-40 <-40 |
UL Temperature Rating | ℃ | UL1581 | 80 80 80 80 80 80 |
Volume Resistivity | Ohm-cm | D257 | 4.0E+15 4.3E+15 4.0E+15 3.8E+15 3.8E+15 1.8E+15 |
Relative Permittivity, 60 Hz |
| D150 | 2.5 3.2 3.5 2.6 3.0 3.5 |
Flammability |
| UL1581 | VW-1 V W-1 V W-1 VW-1 VW-1 VW-1 |
Smoke Density, Non-flame, Ds, max Flame, Ds, max | Dm Dm |
E662 E662 |
80 85 82 81 86 85 140 142 143 138 146 147 |
注：以上数据仅供参考，不能作为我公司质量保证依据。用户可根据您公司设备实际情况及电缆结构具体形式对我公司产品进行应用和适应。
2、OLLOY KMDE系列产品 Parameter ofwire coating extrusion:
1、Please drying material before extruding processing:
Drying Temperature :80-90°C; drying time:2-3hrs
2、Extruding temperature(°C):
Feed Zone Temperature: 180-190 Middle Zone Temperatures : 200-210 Head Zone Temperature:200-210
Neck Temperature: 200-210 Cross-head Temperature: 210-220 Die Temperature:200-220
Melt Temperature:200-220
