| 断裂伸长率 | 18% |
|---|---|
| 封装 | DIP |
| 类型 | 标准料 |
| 密度 | 1.41g/cm3 |
| 牌号 | 12T |
| 批号 | 11+ |
| 销售方式 | 品牌经销 |
| 颜色 | 本色 |
| 用途级别 | 汽车部件 |
| 品牌 | Dupont/杜邦 |
| 厂家(产地) | 美国杜邦 |
| 加工级别 | 注塑级 |
| 特性级别 | 增韧级,增强级,热稳定性,矿物增强 |
| 规格级别 | 矿物增强 |
DuPont Performance Polymers Minlon 12T NC010 Nylon 66 (Unverified Data**) Polymer,Thermoplastic,Nylon,Nylon 66,Nylon 66, 40% Mineral Filled DuPont Performance Polymers 产品说明: 36% 矿物增强增韧聚酰胺 66
Minlon 12T NC010 是一种 36% 矿物增强 增韧 热稳定 聚酰胺 66 树脂，用于注塑成型。
杜邦高性能聚合物提供的信息
DuPont Performance Polymers Minlon 12T NC010 Nylon 66 (Unverified Data**) 物性表
| 物理性能 | 额定值 (公制) | 额定值 (英制) | 测试方法 |
|---|---|---|---|
| 密度 | 1.41 g/cc | 0.0509 lb/in3 | DAM; ISO 1183 |
| 吸水率 | 6.2 % @Thickness 2.00 mm | 6.2 % @Thickness 0.0787 in | DAM; Sim. to ISO 62 |
| 水分吸收 | 1.70 % @Thickness 2.00 mm | 1.70 % @Thickness 0.0787 in | DAM; Sim. to ISO 62 |
| 饱和吸水率 | 1.2 % | 1.2 % | DAM; Immersion 24h; ASTM D570 |
| 线性成型收缩率,Flow | 0.0090 cm/cm | 0.0090 in/in | DAM; ISO 294-4 2577 |
| 线性成型收缩率，横向 | 0.0090 cm/cm | 0.0090 in/in | DAM; ISO 294-4 2577 |
| 机械性能 | 额定值 (公制) | 额定值 (英制) | 测试方法 |
|---|---|---|---|
| 抗张强度(断裂) | 58.0 MPa | 8410 psi | 50%RH; ISO 527-1/-2 |
| 80.0 MPa | 11600 psi | DAM; ISO 527-1/-2 | |
| 抗张强度 | 2.20 MPa @Strain 0.10 %, Temperature 23.0 °C | 319 psi @Strain 0.10 %, Temperature 73.4 °F | 50%RH; ISO 11403-1 -2 |
| 3.34 MPa @Strain 0.400 %, Temperature 150 °C | 484 psi @Strain 0.400 %, Temperature 302 °F | DAM; ISO 11403-1 -2 | |
| 6.31 MPa @Strain 1.10 %, Temperature 150 °C | 915 psi @Strain 1.10 %, Temperature 302 °F | 50%RH; ISO 11403-1 -2 | |
| 10.28 MPa @Strain 1.70 %, Temperature 150 °C | 1491 psi @Strain 1.70 %, Temperature 302 °F | DAM; ISO 11403-1 -2 | |
| 10.73 MPa @Strain 0.200 %, Temperature 0.000 °C | 1556 psi @Strain 0.200 %, Temperature 32.0 °F | DAM; ISO 11403-1 -2 | |
| 11.06 MPa @Strain 2.30 %, Temperature 150 °C | 1604 psi @Strain 2.30 %, Temperature 302 °F | 50%RH; ISO 11403-1 -2 | |
| 12.9 MPa @Strain 0.700 %, Temperature 23.0 °C | 1870 psi @Strain 0.700 %, Temperature 73.4 °F | 50%RH; ISO 11403-1 -2 | |
| 15.3 MPa @Strain 0.300 %, Temperature 0.000 °C | 2220 psi @Strain 0.300 %, Temperature 32.0 °F | 50%RH; ISO 11403-1 -2 | |
| 15.36 MPa @Strain 3.20 %, Temperature 150 °C | 2228 psi @Strain 3.20 %, Temperature 302 °F | DAM; ISO 11403-1 -2 | |
| 15.52 MPa @Strain 4.00 %, Temperature 150 °C | 2251 psi @Strain 4.00 %, Temperature 302 °F | 50%RH; ISO 11403-1 -2 | |
| 18.53 MPa @Strain 6.00 %, Temperature 150 °C | 2688 psi @Strain 6.00 %, Temperature 302 °F | 50%RH; ISO 11403-1 -2 | |
| 18.83 MPa @Strain 4.90 %, Temperature 150 °C | 2731 psi @Strain 4.90 %, Temperature 302 °F | DAM; ISO 11403-1 -2 | |
| 20.3 MPa @Strain 0.300 %, Temperature -40.0 °C | 2940 psi @Strain 0.300 %, Temperature -40.0 °F | 50%RH; ISO 11403-1 -2 | |
| 21.0 MPa @Strain 0.400 %, Temperature 23.0 °C | 3050 psi @Strain 0.400 %, Temperature 73.4 °F | DAM; ISO 11403-1 -2 | |
| 22.3 MPa @Strain 1.60 %, Temperature 23.0 °C | 3230 psi @Strain 1.60 %, Temperature 73.4 °F | 50%RH; ISO 11403-1 -2 | |
| 26.77 MPa @Strain 40.0 %, Temperature 150 °C | 3883 psi @Strain 40.0 %, Temperature 302 °F | 50%RH; ISO 11403-1 -2 | |
| 29.55 MPa @Strain 0.500 %, Temperature -40.0 °C | 4286 psi @Strain 0.500 %, Temperature -40.0 °F | DAM; ISO 11403-1 -2 | |
| 30.3 MPa @Strain 2.90 %, Temperature 23.0 °C | 4390 psi @Strain 2.90 %, Temperature 73.4 °F | 50%RH; ISO 11403-1 -2 | |
| 31.31 MPa @Strain 0.600 %, Temperature 0.000 °C | 4541 psi @Strain 0.600 %, Temperature 32.0 °F | DAM; ISO 11403-1 -2 | |
| 37.9 MPa @Strain 0.800 %, Temperature 0.000 °C | 5500 psi @Strain 0.800 %, Temperature 32.0 °F | 50%RH; ISO 11403-1 -2 | |
| 44.2 MPa @Strain 0.900 %, Temperature 23.0 °C | 6410 psi @Strain 0.900 %, Temperature 73.4 °F | DAM; ISO 11403-1 -2 | |
| 50.4 MPa @Strain 0.800 %, Temperature -40.0 °C | 7310 psi @Strain 0.800 %, Temperature -40.0 °F | 50%RH; ISO 11403-1 -2 | |
| 52.7 MPa @Strain 1.40 %, Temperature 0.000 °C | 7640 psi @Strain 1.40 %, Temperature 32.0 °F | 50%RH; ISO 11403-1 -2 | |
| 55.3 MPa @Strain 1.20 %, Temperature 23.0 °C | 8020 psi @Strain 1.20 %, Temperature 73.4 °F | DAM; ISO 11403-1 -2 | |
| 55.4 MPa @Strain 40.0 %, Temperature 23.0 °C | 8040 psi @Strain 40.0 %, Temperature 73.4 °F | 50%RH; ISO 11403-1 -2 | |
| 57.45 MPa @Strain 1.20 %, Temperature 0.000 °C | 8332 psi @Strain 1.20 %, Temperature 32.0 °F | DAM; ISO 11403-1 -2 | |
| 63.5 MPa @Strain 2.50 %, Temperature 0.000 °C | 9210 psi @Strain 2.50 %, Temperature 32.0 °F | 50%RH; ISO 11403-1 -2 | |
| 65.3 MPa @Strain 1.10 %, Temperature -40.0 °C | 9470 psi @Strain 1.10 %, Temperature -40.0 °F | 50%RH; ISO 11403-1 -2 | |
| 65.9 MPa @Strain 1.60 %, Temperature 23.0 °C | 9560 psi @Strain 1.60 %, Temperature 73.4 °F | DAM; ISO 11403-1 -2 | |
| 72.67 MPa @Strain 1.40 %, Temperature -40.0 °C | 10540 psi @Strain 1.40 %, Temperature -40.0 °F | DAM; ISO 11403-1 -2 | |
| 73.15 MPa @Strain 1.70 %, Temperature 0.000 °C | 10610 psi @Strain 1.70 %, Temperature 32.0 °F | DAM; ISO 11403-1 -2 | |
| 78.0 MPa @Strain 4.00 %, Temperature 23.0 °C | 11300 psi @Strain 4.00 %, Temperature 73.4 °F | DAM; ISO 11403-1 -2 | |
| 79.9 MPa @Strain 24.0 %, Temperature 0.000 °C | 11600 psi @Strain 24.0 %, Temperature 32.0 °F | 50%RH; ISO 11403-1 -2 | |
| 84.2 MPa @Strain 1.60 %, Temperature -40.0 °C | 12200 psi @Strain 1.60 %, Temperature -40.0 °F | 50%RH; ISO 11403-1 -2 | |
| 89.79 MPa @Strain 1.90 %, Temperature -40.0 °C | 13020 psi @Strain 1.90 %, Temperature -40.0 °F | DAM; ISO 11403-1 -2 | |
| 92.72 MPa @Strain 4.20 %, Temperature 0.000 °C | 13450 psi @Strain 4.20 %, Temperature 32.0 °F | DAM; ISO 11403-1 -2 | |
| 101.96 MPa @Strain 2.40 %, Temperature -40.0 °C | 14788 psi @Strain 2.40 %, Temperature -40.0 °F | DAM; ISO 11403-1 -2 | |
| 116.2 MPa @Strain 8.00 %, Temperature -40.0 °C | 16850 psi @Strain 8.00 %, Temperature -40.0 °F | 50%RH; ISO 11403-1 -2 | |
| 伸长率 (断裂) | 18 % | 18 % | DAM; ISO 527-1/-2 |
| 40 % | 40 % | 50%RH; ISO 527-1/-2 | |
| 拉伸模量 | 2.00 GPa | 290 ksi | 50%RH; ISO 527-1/-2 |
| 4.90 GPa | 711 ksi | DAM; ISO 527-1/-2 | |
| 弯曲模量 | 1.80 GPa | 261 ksi | 50%RH; ISO 178 |
| 4.50 GPa | 653 ksi | DAM; ISO 178 | |
| 割线模量 | 0.0997 GPa @Strain 38.0 %, Temperature 80.0 °C | 14.5 ksi @Strain 38.0 %, Temperature 176 °F | 50%RH; ISO 11403-1 -2 |
| 0.127 GPa @Strain 30.9 %, Temperature 100 °C | 18.5 ksi @Strain 30.9 %, Temperature 212 °F | DAM; ISO 11403-1 -2 | |
| 0.154 GPa @Strain 30.9 %, Temperature 80.0 °C | 22.3 ksi @Strain 30.9 %, Temperature 176 °F | DAM; ISO 11403-1 -2 | |
| 0.172 GPa @Strain 19.0 %, Temperature 100 °C | 24.9 ksi @Strain 19.0 %, Temperature 212 °F | 50%RH; ISO 11403-1 -2 | |
| 0.233 GPa @Strain 14.0 %, Temperature 80.0 °C | 33.8 ksi @Strain 14.0 %, Temperature 176 °F | 50%RH; ISO 11403-1 -2 | |
| 0.306 GPa @Strain 12.9 %, Temperature 80.0 °C | 44.4 ksi @Strain 12.9 %, Temperature 176 °F | DAM; ISO 11403-1 -2 | |
| 0.31766 GPa @Strain 9.40 %, Temperature 100 °C | 46.073 ksi @Strain 9.40 %, Temperature 212 °F | DAM; ISO 11403-1 -2 | |
| 0.356 GPa @Strain 7.50 %, Temperature 100 °C | 51.6 ksi @Strain 7.50 %, Temperature 212 °F | 50%RH; ISO 11403-1 -2 | |
| 0.428 GPa @Strain 6.00 %, Temperature 80.0 °C | 62.1 ksi @Strain 6.00 %, Temperature 176 °F | 50%RH; ISO 11403-1 -2 | |
| 0.467 GPa @Strain 10.0 %, Temperature 23.0 °C | 67.7 ksi @Strain 10.0 %, Temperature 73.4 °F | 50%RH; ISO 11403-1 -2 | |
| 0.542 GPa @Strain 3.60 %, Temperature 100 °C | 78.6 ksi @Strain 3.60 %, Temperature 212 °F | 50%RH; ISO 11403-1 -2 | |
| 0.607 GPa @Strain 3.00 %, Temperature 100 °C | 88.0 ksi @Strain 3.00 %, Temperature 212 °F | DAM; ISO 11403-1 -2 | |
| 0.627 GPa @Strain 4.50 %, Temperature 80.0 °C | 90.9 ksi @Strain 4.50 %, Temperature 176 °F | DAM; ISO 11403-1 -2 | |
| 0.680 GPa @Strain 2.50 %, Temperature 80.0 °C | 98.6 ksi @Strain 2.50 %, Temperature 176 °F | 50%RH; ISO 11403-1 -2 |
