| 牌号 | DR48 |
|---|---|
| 用途级别 | 注塑级 |
| 产地/厂家 | 美国 |
| 品牌 | 基础创新 |
| 型号 | DR48 |
①原料描述部分
| 规格级别： | --- | 外观颜色： | --- |
| 用途概述： | --- | ||
| 备注说明： | 特性：17%玻纤增强组燃，UL94 V-0/5VA额定。 | ||
②原料技术数据
| 性能项目 | 试验条件[状态] | 测试方法 | 测试数据 | 数据单位 | ||||||||||
| 其它性能 | 阻燃性 | --- | --- | 0.9 | mm | |||||||||
| 物理性能 | 比重 | --- | --- | 1.53 | --- | |||||||||
| 吸水率 | --- | --- | 0.07 | % | ||||||||||
| 模具收缩率 | --- | --- | 4-6 | E-3 | ||||||||||
| 增强 | --- | --- | 15 | % | ||||||||||
| 机械性能 | 拉伸强度（断裂点） | --- | --- | 93 | MPa | |||||||||
| 弯曲模量 | --- | --- | 5030 | MPa | ||||||||||
| 冲击强度缺口 | 23℃ | --- | 53 | J/m | ||||||||||
| 硬扩度洛氏R | --- | --- | 118 | --- | ||||||||||
| --- | --- |
|
| ||||||||||
| 电气性能 | 损耗因数 | --- | --- | 0.02 | --- | |||||||||
| 介电常数 | --- | --- | 3.4 | --- | ||||||||||
| 体积电阻 | --- | --- | 4.00E+16 | Ohm-cm | ||||||||||
| 热 性 能 | 线膨胀系数 | --- | --- | 2.0E-05 | 1/℃ | |||||||||
| 热变形温度 | --- | --- | 210 | ℃ | ||||||||||
| 热变形温度 | --- | --- | 182 | ℃ | ||||||||||
| 阻燃性 | --- | --- | V-0 | --- | ||||||||||
| 阻燃性 | --- | --- | 5V | --- | ||||||||||
| 阻燃性 | --- | --- | 3 | mm | ||||||||||
