| 加工定制 | 是 |
|---|---|
| 类型 | 平板硫化机 |
| 样式 | 立式 |
| 运行方式 | 真空硫化机 |
| 最大宽度 | 600（㎜） |
| 切割刀宽 | 00（㎜） |
| 最大行程 | 250（㎜） |
| 公称合模力 | 2500（MN） |
| 电动机功率 | 31（KW） |
| 外形尺寸 | 4.1*2.4*2.5（m） |
| 重量 | 11500（kg） |
| 品牌 | 其他 |
| 型号 | TW-Z4-250t |
| ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| 全自动真空平板硫化成型机系列 | |||||||
| Automatic vacuum plate vulcanizing molding machine series | |||||||
| 机台特点 采用双动力、双油泵、双马达、双冷却器，两轴完全独立工作。 油路系统特殊设计，无振动，稳定性好，出入模、上升下降比同行机器要快。 真空度高，采用平均抽法，可使产品稳定，提高品质及产能。 真空储气罐基座式，储气空间大。 新型掀模机械设计，耐用寿命长，出入模静音、快速、平稳。 Machine characteristics Double powers, double oil pumps, double motors and double oil coolers are applied for the two axles to work independently. The oil system is unique in design with good stability, faster lift-up and lift-down speed compared with other brands when unloading/loading mold. High vacuum and the average pumping method are applied for the manufacturing of stable products and improving the quality and productivity. The pedestal vacuum oxygen tank provides large oxygen storage space.The new mold raising mechanism design has the advantages of long working life, quiet mold-unloading/loading, fastness and stability. | |||||||
| 适用产品 汽车配件、橡胶迫紧、医疗用橡胶、O型环、按键、民用橡胶、工业橡胶、瓶塞等。 Applicable products Auto parts, rubber packing, medical rubber, O ring, key, rubber for civil use, industrial rubber and bottle stopper, etc. | |||||||
| 技术参数Specificaton | |||||||
| 机型Type | TWZ-100T | TWZ-200T | TWZ-250T | TWZ-300T | TWZ-350T | TWZ400T | TWZ-500T |
| 出力Clapping force（TON） | 100 | 200 | 250 | 300 | 350 | 400 | 500 |
| 行程Stroke（MM） | 250 | 250 | 300 | 300 | 300 | 300 | 300 |
| 工作台面Working Plate Size（MM） | 上：400×400 下：450×460 | 上：536×536 下：540×560 | 上：600×600 下：600×650 | 上：600×600 下：650×650 | 上：700×700 下：750×750 | 上：750×750 下：800×800 | 上：850×850 下：900×900 |
| 主油缸直径Dimeter of cyhnder（MM） | 250 | 355 | 400 | 450 | 475 | 500 | 560 |
| 马力 Horse powet（HP） | 7.5×2 | 10×2 | 10×2 | 10×2 | 15×2 | 15×2 | 15×2 |
| 电热功率Heater power（KW） | 16 | 25 | 31 | 34 | 40 | 57 | 58 |
| 总功率Total power（KW） | 30 | 45 | 52 | 55 | 68 | 83 | 86 |
| 开模方式Type of mold openning | 上升下降-出入模-2RT/3RT/4RT(轨道开模)UP/DownIn/Out-2RT/3RT/4RT | ||||||
| 重量Gross weight（KG） | 7000 | 9000 | 11500 | 13500 | 16000 | 20000 | 35000 |
| 机台尺寸Machine size（MM） | 2600×2000×2100 | 3000×2200×2500 | 4100*2400*2500 | 3500×2700×2600 | 3700*2800*2700 | 3700*2800*2900 | 3900*2900*3000 |
江苏拓威机械有限公司（原金坛市建阳机械有限公司）是一家生产橡胶成型机专业制造商。拥有一支经验丰富技术团队，不断研发、制造、销售并提供一服务。为全球打造高品质橡胶设备。是橡胶加工厂商首选品牌。
公司成立于1996年，位于老牌重工业城市常州金坛，占地面积30000平方米，公司主要生产：硅橡胶注射机、液态硅胶注射机、液体硅胶泵料机、真空平板硫化机、大型柱式、框式平板硫化机等各种非标设备。
我们以诚信为本﹑质优价廉取胜，时刻倾听每位客户的意见，从而提高产品的质量与信誉，在平等互利的基础上共同发展，共创佳绩。拓威机械将继续致力于质量第一，客户至上的企业宗旨，以更优﹑更新的产品及优质的服务，不断提高。
Jiangsu Tuowei Machinery Co.,Ltd (Jintan Jianyang Machinery Co.,Ltd) is a professional manufacturer of rubber forming machine. With a technical team full of experience, the company constantly researches and develops, manufactures, sells and provides the first class service. It Makes high quality rubber equipment for the world and is first choice of rubber processing manufacturers.
Located in the old city of heavy industry, Jintan, Changzhou, the company was founded in 1996 covering an area of 30000 square meters. The company mainly produces: silicon rubber injection machine, liquid silicon rubber injection machine, liquid silicon rubber pump machine, vacuum plate vulcanizing machine, large column type and frame form plate vulcanizing machine and the other non-standard equipment.
We base on sincerity, win with high quality and low price and listen to every customer’s opinion at any time in order to improve product quality and reputation and develop and win together on equality and mutual benefit. Tuowei Machinery will continue to focus on the enterprise tenet of “Quality First, Customer First” and constantly improve with more excellent and newer products and high quality service.
