价格:
￥38.70/公斤
品牌:POM,PMMA,PBT,PET ,PA66,PA6 PC,
类型:标准料
牌号:101F
起订:25公斤
供应:90000公斤
发货:3天内
立即购买
| 类型 | 标准料 |
| 牌号 | 101F |
| 销售方式 | 品牌经销 |
| 颜色 | 透明 |
| 用途级别 | 注塑级 |
| 品牌 | 搜塑 |
| 厂家(产地) | 搜塑工程塑胶 |
| 加工级别 | 注塑级 |
| 特性级别 | 标准级 |
| 规格级别 | 注塑级 |
| ? | PA66 101F 搜塑工程塑胶有限公司 物性数据 |
①原料描述部分 | 规格级别： | 特殊级、注塑级 | 外观颜色： | --- |
| 用途概述： | --- |
| 备注说明： | --- |
?
②原料技术数据 | 性能项目 | 试验条件[状态] | 测试方法 | rame="void" width="100%" cellpadding="0" cellspacing="0" border="1"> | 测试数据 | | DAM | 50%RH | | 数据单位 |
| 基本性能 | 吸水率 | 24hr | ASTM D-570 | rame="void" width="100%" cellpadding="0" cellspacing="0" border="1"> | 1.2 | - | | % |
| 密度 | --- | ASTM D-792 | rame="void" width="100%" cellpadding="0" cellspacing="0" border="1"> | 1.14 | - | | g/cm3 |
| 物理性能 | 比重 | --- | ASTM D-792 | rame="void" width="100%" cellpadding="0" cellspacing="0" border="1"> | 1.14 | - | | --- |
| 模具收缩率 | --- | --- | rame="void" width="100%" cellpadding="0" cellspacing="0" border="1"> | 1.5 | - | | % |
| 阻燃性 | --- | UL 94 | rame="void" width="100%" cellpadding="0" cellspacing="0" border="1"> | 0.71 | - | | mm |
| 机械性能 | 拉伸强度 | --- | ASTM D-638 | rame="void" width="100%" cellpadding="0" cellspacing="0" border="1"> | 83 | 64 | | MPa |
| 断裂拉伸强度 | --- | ASTM D-638 | rame="void" width="100%" cellpadding="0" cellspacing="0" border="1"> | 83 | - | | MPa |
| 断裂伸长率 | --- | ASTM D-638 | rame="void" width="100%" cellpadding="0" cellspacing="0" border="1"> | 50 | ＞300 | | % |
| 屈服伸长率 | --- | ASTM D-638 | rame="void" width="100%" cellpadding="0" cellspacing="0" border="1"> | 4 | - | | % |
| 弯曲模量 | --- | ASTM D-790 | rame="void" width="100%" cellpadding="0" cellspacing="0" border="1"> | 2800 | 1210 | | MPa |
| IZOD缺口冲击强度 | --- | ASTM D-256 | rame="void" width="100%" cellpadding="0" cellspacing="0" border="1"> | 53 | 105 | | J/m |
| 电气性能 | 表面电阻率 | --- | ASTM D-257 | rame="void" width="100%" cellpadding="0" cellspacing="0" border="1"> | 1014 | - | | Ω |
| 体积电阻率 | --- | ASTM D-257 | rame="void" width="100%" cellpadding="0" cellspacing="0" border="1"> | 1015 | - | | Ω.cm |
| 介电强度 | 3.2mm | ASTM D-149 | rame="void" width="100%" cellpadding="0" cellspacing="0" border="1"> | 16.5 | - | | kv/mm |
| 介电强度 | 1.6mm | ASTM D-150 | rame="void" width="100%" cellpadding="0" cellspacing="0" border="1"> | 23.2 | - | | kv/mm |
| 介电常数 | 103Hz | ASTM D-150 | rame="void" width="100%" cellpadding="0" cellspacing="0" border="1"> | 4.0 | - | | --- |
| 介电常数 | 106Hz | ASTM D-150 | rame="void" width="100%" cellpadding="0" cellspacing="0" border="1"> | 3.7 | - | | --- |
| 损耗因数 | 102Hz | ASTM D-150 | rame="void" width="100%" cellpadding="0" cellspacing="0" border="1"> | 0.01 | - | | --- |
| 损耗因数 | 103Hz | ASTM D-150 | rame="void" width="100%" cellpadding="0" cellspacing="0" border="1"> | 0.02 | - | | --- |
| 损耗因数 | 106Hz | ASTM D-150 | rame="void" width="100%" cellpadding="0" cellspacing="0" border="1"> | 0.02 | - | | --- |
| 热 性 能 | 熔点 | --- | ASTM D-3418 | rame="void" width="100%" cellpadding="0" cellspacing="0" border="1"> | 262 | - | | ℃ |
| 热变形温度 | 0.45MPa | ASTM D-648 | rame="void" width="100%" cellpadding="0" cellspacing="0" border="1"> | 210 | - | | ℃ |
| 热变形温度 | 1.80MPa | ASTM D-648 | rame="void" width="100%" cellpadding="0" cellspacing="0" border="1"> | 65 | - | | ℃ |
