| 品牌 | 益通 |
|---|---|
| 型号 | 型号齐全 |
| 公称通径DN(mm) | 长度L(mm) | 轴向压缩 | 轴向拉伸 | 横向位移 | 偏向角度 |
| 32 | 95 | 8 | 4 | 8 | 15° |
| 40 | 95 | 8 | 5 | 8 | 15° |
| 50 | 105 | 8 | 5 | 8 | 15° |
| 65 | 115 | 12 | 6 | 10 | 15° |
| 80 | 135 | 12 | 6 | 10 | 15° |
| 100 | 150 | 18 | 10 | 12 | 15° |
| 125 | 165 | 18 | 10 | 12 | 15° |
| 150 | 180 | 18 | 10 | 12 | 15° |
| 200 | 210 | 25 | 14 | 15 | 15° |
| 250 | 230 | 25 | 14 | 15 | 15° |
| 300 | 245 | 25 | 14 | 15 | 15° |
| 350 | 255 | 25 | 15 | 15 | 15° |
| 400 | 255 | 25 | 15 | 15 | 12° |
| 450 | 255 | 25 | 15 | 22 | 12° |
| 500 | 255 | 25 | 16 | 22 | 12° |
| 600 | 260 | 25 | 16 | 22 | 12° |
| 700 | 260 | 25 | 16 | 22 | 12° |
| 800 | 260 | 25 | 16 | 22 | 12° |
| 900 | 260 | 25 | 16 | 22 | 10° |
| 1000 | 260 | 25 | 16 | 22 | 10° |
| 1200 | 260 | 26 | 18 | 24 | 10° |
| 1400 | 450 | 28 | 20 | 26 | 10° |
| 1600 | 500 | 35 | 25 | 30 | 10° |
| 1800 | 500 | 35 | 25 | 30 | 10° |
| 2000 | 550 | 35 | 25 | 30 | 10° |
