| 性能项目 | 试验条件[状态] | 测试方法 | 测试数据 | 数据单位 | | 基本性能 | 吸水率 | --- | ASTM D-570 | 0.22 | % | | 熔体流动速率 | --- | ASTM D-1238 | 9.0 | g/10min | | 物理性能 | 比重 | --- | ASTM D-792 | 1.41 | --- | | --- | | | --- | | --- | | | | | 机械性能 | 拉伸强度 | --- | ASTM D-638 | 62 | MPa | | 断裂伸长率 | --- | ASTM D-638 | 60 | % | | 抗弯强度 | --- | ASTM D-790 | 92 | MPa | | 抗弯模数 | --- | ASTM D-790 | 2.65 | GPa | | 剪切强度 | --- | ASTM D-732 | 56 | MPa | | --- | | | | | 抗张冲击强度 | --- | ASTM D-1822 | 120 | kj/m2 | | 洛氏硬度 | --- | ASTM D-785 | M80（R115） | --- | | 电气性能 | 漏电流路形成指数 | --- | IEC(CTI) | 600 | V | | 绝缘强度 | 3mmt | ASTM D-149 | 19 | MV/m | | 体积电阻率 | --- | ASTM D-257 | 4 | ×1012Ω.cm | | 介电常数 | 50Hz | --- | 3.7 | --- | | 介电常数 | 106Hz | ASTM D-150 | 3.7 | --- | | 损耗因素 | 50Hz | ASTM D-150 | 0.005 | --- | | 损耗因素 | 106Hz | ASTM D-150 | 0.005 | --- | | 耐电弧性 | --- | ASTM D-495 | ＞200 | sec | | 热 性 能 | 熔点 | --- | DSC | 166 | ℃ | | 热变形温度 | 0.45MPa | ASTM D-648 | 158 | ℃ | | 热变形温度 | 1.82MPa | ASTM D-648 | 110 | ℃ | | 线膨胀系数 | --- | ASTM D-696 | 10 | ×10-5℃ | | 可燃性 | --- | UL 94 | HB | --- | |
|
|
|
|
| |
| |
